Spare parts TOYOTA HARRIER (_U3_) 3.3 Hybrid 4WD (MHU38_, MHU38W)
General information
| Code: | 0242236599 |
| Brand: | BOSCH |
| Title: | Spark Plug |
| Tag: | Double Iridium |
| Car: | FORD |
Criteria
| Electrode Gap [mm]: | 1,1 mm |
| Tightening Torque [Nm]: | 28 Nm |
| Thread Size: | M 14 x 1,25 |
| Thread Length [mm]: | 19 mm |
| Spanner Size: | 16 |
| Spark Position [mm]: | 4 mm |
| Number of pins: | 1 -pin connector |
Show all
Show less
General information
| Code: | 0258986602 |
| Brand: | BOSCH |
| Title: | Oxygen Sensor |
| Car: | ŠKODA-VW |
Criteria
| Number of circuits: | 4 |
| Recommended change interval [km]: | 160000 km |
| Connector/Clamp: | Connector may need adjustment |
Show all
Show less
General information
| Code: | 060717215012 |
| Brand: | MAGNETI MARELLI |
| Title: | Ignition Coil |
| Car: | TOYOTA |
General information
| Code: | 062711000053 |
| Brand: | MAGNETI MARELLI |
| Title: | Spark Plug |
| Car: | TOYOTA |
Criteria
| Spark Plug: | 1 - Earthed Electrode |
| Electrode Gap [mm]: | 1,1 mm |
| Thread Size: | M14 x 1.25 |
| Thread Length [mm]: | 19 mm |
| Spanner Size: | 16 |
| Spark Plug: | with resistor |
| Technical Information: | Iridium |
Show all
Show less
General information
| Code: | 0986452044 |
| Brand: | BOSCH |
| Title: | Oil Filter |
| Car: | TOYOTA |
Criteria
| Filter type: | Spin-on Filter |
| Height [mm]: | 89 mm |
| Thread Size: | 3/4" 16 UNF-2B |
| Outer Diameter [mm]: | 78 mm |
| Gasket outside diameter [mm]: | 72 mm |
| Gasket inside diameter [mm]: | 62 mm |
| Bypass Valve Opening Pressure [bar]: | 1 bar |
| Supplementary Article/Supplementary Info 2: | with one anti-return valve |
| Quantity: | 1 |
Show all
Show less
General information
| Code: | 0986479614 |
| Brand: | BOSCH |
| Title: | Brake Disc |
| Car: | TOYOTA |
Criteria
| Outer Diameter [mm]: | 288 mm |
| Brake Disc Thickness [mm]: | 10 mm |
| Minimum thickness [mm]: | 8,5 mm |
| Height [mm]: | 69,4 mm |
| Bolt Hole Circle Ø [mm]: | 114,3 mm |
| Brake Disc Type: | solid |
| Centering Diameter [mm]: | 62,01 mm |
| Number of Holes: | 5 |
| Surface: | Oiled |
| Fulfils ECE standard: | ECE-R90 |
| Bore Diameter up to [mm]: | 14,5 mm |
Show all
Show less
General information
| Code: | 0986494218 |
| Brand: | BOSCH |
| Title: | Brake Pad Set, disc brake |
| Car: | TOYOTA |
Criteria
| Supplementary Article/Supplementary Info 2: | with anti-squeak plate |
| Supplementary Article/Supplementary Info 2: | with mounting manual |
| Material: | Low-Metallic |
| Test Mark: | ECE-R90 |
| WVA Number: | 23989 |
| Thickness [mm]: | 17,3 mm |
| Width [mm]: | 140,8 mm |
| Height [mm]: | 59,5 mm |
Show all
Show less
General information
| Code: | 0986494224 |
| Brand: | BOSCH |
| Title: | Brake Pad Set, disc brake |
| Car: | TOYOTA |
Criteria
| Article number of recommended accessories: | 1 987 474 697 |
| Product must be determined on the vehicle or the motor: | yes |
| Material: | Low-Metallic |
| Test Mark: | ECE-R90 |
| WVA Number: | 23967 |
| Thickness [mm]: | 15,3 mm |
| Width [mm]: | 101,5 mm |
| Height [mm]: | 43,3 mm |
Show all
Show less
General information
| Code: | 152071758739 |
| Brand: | MAGNETI MARELLI |
| Title: | Oil Filter |
| Car: | NISSAN |
Criteria
| Height [mm]: | 89 mm |
| Filter type: | Spin-on Filter |
| Thread Size: | 3/4"-16 |
| Outer Diameter [mm]: | 86,2 mm |
Show all
Show less
General information
| Code: | 152071758778 |
| Brand: | MAGNETI MARELLI |
| Title: | Oil Filter |
| Car: | FORD |
Criteria
| Height [mm]: | 85 mm |
| Filter type: | Spin-on Filter |
| Thread Size: | 3/4"-16 |
| Outer Diameter [mm]: | 77 mm |
Show all
Show less
