• PM000700 - Piston ET ENGINETEAM
   |    Brand: ET ENGINETEAM   |    Code: PM000700   |    Title: Piston

Piston - PM000700 ET ENGINETEAM - 51025006023, 51025006031, 51025117385

Car: Man TGA F200 Neoplan Van Hool D2866-LF23/24/25/26/27/28/37/38 D2866-LOH27/28/29/30/32/33/34/35/37/38 D2866-LUH23/24/25/27/28/29/34/35/36/50/51/52
Piston - PM000700 ET ENGINETEAM - 51025006023, 51025006031, 51025117385
Weight  : 3,80 kg
Cylinder Bore [mm]: 128 mm
Standard Size [STD]: yes
Bolt Ø [mm]: 46 mm
Bolt length [mm]: 105 mm
Compression Height [mm]: 89,75 mm
Recess Depth 1 [mm]: 22 mm
Valve pocket depth 1 [mm]: 1,9 mm
Valve pocket depth 2 [mm]: 1,9 mm
Recess Diameter [mm]: 80 mm
Supplementary Article/Supplementary Info: with piston rings
We recommend!
Netto price $252.38 ($252.38 without VAT 0%)
Your price -30% $176.67 ($176.67 without VAT 0%)
Stock: 4 pcs
Supplier: > 23 pcs

EAN: 8592779003433

Unfortunately, there is no additional description available for this product.

Categories

Pistons / liners / rings > Complete piston with rings and pin

Used in

Reference Numbers

Show all Show less

Alternatives

99330600 - KOLBENSCHMIDT Piston with rings and pin

99330600, Piston with rings and pin, KOLBENSCHMIDT, 51.02511-7389, 51.02511-7385, 51.02500-6031, 51.02500-6023, 2290400, 87-143800-30, 51.02500.6023, 51.02500.6031, 51.02511.7385, 51.02511.7389, 51025006023, 51025006031, 51025117385, 51025117389

General information

Code:99330600
Brand: KOLBENSCHMIDT
Title:Piston with rings and pin
Car:MAN
Weight  :3,95 kg

Criteria

Production Number: 128053
Cylinder Bore [mm]: 128 mm
Compression Height [mm]: 89,75 mm
Length [mm]: 141,75 mm
Recess Depth 1 [mm]: 22 mm
Valve pocket depth 1 [mm]: 1,9 mm
Valve pocket depth 2 [mm]: 1,9 mm
Recess Diameter [mm]: 80 mm
Component Number: 82139
Component Number: 49535
Component Number: 72850
Standard Size [STD]: yes
Bolt Ø [mm]: 46 mm
Bolt length [mm]: 105 mm
Show all Show less
Netto price: $289.10 ($289.10 without VAT 0%)
Your price: -40% $173.46 ($173.46 without VAT 0%)
Stock: 0 pcs
Supplier: 0 pcs

020320286602 - OE Germany Piston

020320286602, Piston, OE Germany, 51.02500.6023, 51.02500.6031, 51.02500.6040, 51.02511.0430, 51.02511.0434, 51.02511.7385, 51.02511.7389, 2290400, 3.10132, 99330600

General information

Code:020320286602
Brand: OE Germany
Title:Piston
Car:MAN
Weight  :3,83 kg

Criteria

Cylinder Bore [mm]: 128 mm
Length [mm]: 142 mm
Compression Height [mm]: 89,75 mm
Valve pocket depth 1 [mm]: 2,1 mm
Valve pocket depth 2 [mm]: 1,9 mm
Recess Depth 1 [mm]: 22 mm
Recess Diameter [mm]: 80 mm
Bolt Ø [mm]: 46 mm
Bolt length [mm]: 105 mm
Surface: Coated
Show all Show less
Netto price: $163.33 ($163.33 without VAT 0%)
Your price: -30% $114.33 ($114.33 without VAT 0%)
Stock: 0 pcs
Supplier: 16 pcs

2290400 - MAHLE Piston

2290400, Piston, MAHLE, 51025006023, 51025006031, 51025006040, 51025110430, 51025110434, 51025117385, 51025117389, 87-143800-30, 99330600, 87-143800-32, 87-71580

General information

Code:2290400
Brand: MAHLE
Title:Piston
Car:MAN
Weight  :4,14 kg

Criteria

Standard Size [STD]: yes
Cylinder Bore [mm]: 128,0 mm
Length [mm]: 141,8 mm
Compression Height [mm]: 89,75 mm
Bolt length [mm]: 105,0 mm
Bolt Ø [mm]: 46,0 mm
Recess Depth 1 [mm]: 22,0 mm
Recess Diameter [mm]: 80,0 mm
Valve pocket depth 1 [mm]: 2,1 mm
Valve pocket depth 2 [mm]: 1,9 mm
Machined: with cut-out for oil jet
Surface: Coated
Supplementary Article/Info 2: with piston ring carrier
Supplementary Article/Info 2: without cooling duct
Top land height [mm]: 18,45 mm
Production Number: 128 L 74
Piston Clearance [mm]: 0,14 mm
Component Number: 1. T 4.0 Cr
Component Number: 2. M 3.0 Cr P
Component Number: 3. DSF 4.0 Cr
Packaging length [cm]: 15,0 cm
Packaging width [cm]: 15,00 cm
Packaging height [cm]: 21,00 cm
Net Weight [g]: 3805 g
Show all Show less
Netto price: $436.95 ($436.95 without VAT 0%)
Your price: -30% $305.86 ($305.86 without VAT 0%)
Stock: 0 pcs
Supplier: Check

87-143800-30 - NÜRAL Piston

87-143800-30, Piston, NÜRAL, 51.02500-6023, 2290400, 99330600

General information

Code:87-143800-30
Brand: NÜRAL
Title:Piston
Car:MAN
Weight  :3,80 kg

Criteria

Height [mm]: 141,8 mm
Cylinder Bore [mm]: 128 mm
Machined: with cut-out for oil jet
Bolt Ø [mm]: 46 mm
Supplementary Article/Info 2: with piston ring carrier
Component Number: 08-143800-00
Compression Height [mm]: 89,75 mm
Recess Diameter [mm]: 80 mm
Bolt length [mm]: 105 mm
Recess Depth 1 [mm]: 22 mm
Valve pocket depth 1 [mm]: 1,9 mm
Standard Size [STD]: yes
Piston Clearance [mm]: 0,15 mm
Show all Show less
Netto price: $232.76 ($232.76 without VAT 0%)
Your price: -30% $162.93 ($162.93 without VAT 0%)
Stock: 0 pcs

MEC850850 - MEC-DIESEL Piston

MEC850850, Piston, MEC-DIESEL, 51025006023, 51025006031, 51025006040, 51025110430, 51025110434, 51025117385, 51025117389, 000008508508, 2290400, 8714380030, 99330600, 31-03578-000, 8714380032, 3578000, 8771580, 3578000.09, 39-03578-000, 850850

General information

Code:MEC850850
Brand: MEC-DIESEL
Title:Piston
Car:MAN
Weight  :3,80 kg

Criteria

Length [mm]: 141,75 mm
Bore Ø [mm]: 128 mm
Surface: Chrome ceramic coated
Surface: Coated
Bolt Ø [mm]: 46 mm
Supplementary Article/Info 2: with piston ring carrier
Compression Height [mm]: 89,75 mm
Recess Diameter [mm]: 80 mm
Bolt length [mm]: 105 mm
Recess Depth 1 [mm]: 22 mm
Top land height [mm]: 18,45 mm
Valve pocket depth 1 [mm]: 2,1 mm
Valve pocket depth 2 [mm]: 1,9 mm
Standard Size [STD]: yes
Show all Show less
Netto price: $216.62 ($216.62 without VAT 0%)
Your price: -30% $151.63 ($151.63 without VAT 0%)
Stock: 0 pcs
Supplier: > 23 pcs
